Although small, it is mighty. With its long range and two switching outputs, SensoPart’s BlueLight subminiature sensor, FT 10-BHD, is suited for an extensive range of applications, while offering extremely compact dimensions.
The BlueLight subminiature sensor not only has the longest range on the market – 150 mm on white/grey and 120 mm on black – but also comes with an adjustable scanning range instead of the standard fixed focus, as well as two independently adjustable switching outputs. If you’re wondering just how small it actually is, it’s 21.1 x 14.6 x 8mm, meaning it can be installed in close proximity to the process – even fitted directly on a robot gripper.
Application Examples:
Features:
- Sub-miniature sensor with BlueLight technology and precise, adjustable background suppression
- Precise and reliable switching behavior with strongly light-absorbing objects
- Reliable operation without reflector – even with critical surfaces
- Two physical switching outputs
- Sensor settings via teach-in, control input, and IO-Link
- No blind zone in Detect All mode
