icotek KVT 80 gray

The KVT 80 split cable glands are designed for routing and sealing cables with connectors. By assembling the two frame halves with the screws provided, the grommets provide sufficient pressure on the routed cables to obtain a high degree of strain relief. The KVT 80 can be fitted to a wall thickness from 1.5 mm to 10 mm (0,059 to 0,394″). A flat rubber gasket is included in the shipment.

Note:
When mounting the KVT 80 on sheet metal, we recommend the following torque values:
1.5 mm (0,059″) sheet = 1 Nm | 2 – 10 mm (0,079 – 0,394″) sheet = 1.5 Nm

• Insertion of pre-terminated cables
• Warranty on pre-terminated cables remains
• Retrofits, repairs and maintenance can be done much more easily and quickly
• High cable density, wide variety of grommets
• Fast and easy assembly from the front side
• Strain relief according to EN 62444

Specifications
