The KT-DPF grommets accept a wide range of cable diameters. A great benefit when the exact cable diameter is not known in advance. Due to the flexibility and unique pyramid shape, routing and flexible positioning of rigid cables is much easier compared to using conventional cable glands.
The KT-DPF grommets are not split and therefore only usable for cables without connectors.
Cutting of KT-DPF grommets: Cable diameter less 20%. It is recommended that additional strain relief be provided for the cables using a cable tie.
Specifications:
IP rating (EN 60529) IP54
UL Type (UL 50E) UL Type 12
Material Elastomer
Flame class UL94-V0, self-extinguishing
Operating temperature -40 C° to 100 C°
Properties silicone free, halogen free
Advantages & Benefits:
Large clamping range of 3 to 26 mm with only 3 grommets
Ideal for wiring non pre-terminated cables locally
Easy storage
