$367.00
Retro-Reflex Sensor
Features at a Glance
Optical Data |
|
|---|---|
| Range | 6,500 mm |
| Reference Reflector/Reflector Foil | RQ100BA |
| Min. Distance to Reflector | 100 mm |
| Switching Hysteresis | < 15 % |
| Light Source | Red Light |
| Polarization Filter | yes |
| Service Life (T = +25 °C) | 100,000 h |
| Max. Ambient Light | 10,000 Lux |
| Opening Angle | 5 ° |
| Two-Lens Optic | yes |
Laser Distance Sensor Features at a Glance Graphical display for easy operation Analog output (0…10 V/4…20 mA) Secure detection of black objects also in extremely inclined positions with wintec Reliable in case of glossy objects with wintec 2 mutually independent switching outputs Optical Data Working Range 50 … 3,050 mm Measuring Range 3,000 mm Reproducibility maximum 1 mm Linearity Deviation (200…3050 mm) … Continue reading OY1P303P0102 →
Add to cart
Laser Distance Sensor Features at a Glance 2 mutually independent switching outputs Wide working range and precise detection thanks to DS technology No interactive influence Built-in acceleration sensor Optical Data Working Range 0 … 10,000 mm Setting Range 50 … 10,000 mm Reproducibility maximum 3 mm* Linearity Deviation 10 mm* Switching Hysteresis < 15 mm Light Source Laser (red) Wavelength 660 nm Service Life (T = +25 … Continue reading P1PY111 →
Add to cart
Laser Distance Sensor Features at a Glance Response time: < 660 µs (speed-mode) High resolution: 8 µm (resolution-mode) Linearity: 0,1 % (resolution-mode) Zoom function Measured value independent of material, color and brightness Optical Data Working Range 30 … 80 mm Measuring Range 50 mm Resolution 8 µm Resolution (Speed-Mode) 12 µm Linearity 0.1 % Linearity (Speed-Mode) 0.2 % Linearity Deviation 50 µm Light Source Laser (red) … Continue reading CP08MHT80 →
Add to cart
Laser Distance Sensor Features at a Glance Analog output: 4…20 mA Wide working range and precise detection thanks to DS technology No interactive influence Intuitive operating concept Optical Data Working Range 0 … 10,000 mm Setting Range 50 … 10,000 mm Reproducibility maximum 3 mm* Linearity Deviation 10 mm* Light Source Laser (red) Wavelength 660 nm Service Life (T = +25 °C) 100,000 h Laser Class (EN 60825-1) … Continue reading P1PY108 →
Add to cart
