$830.00
Contrast Sensor
Features at a Glance
Optical Data |
|
|---|---|
| Working Range | 50 … 100 mm |
| Measuring Range | 50 mm |
| Resolution | 20 mV |
| Switching Hysteresis | 200 mV |
| Light Source | Laser (red) |
| Wavelength | 660 nm |
| Service Life (T = +25 °C) | 100,000 h |
| Laser Class (EN 60825-1) | 2 |
| Max. Ambient Light | 10,000 Lux |
| Light Spot Diameter | 0.5 mm |
| at a Distance of | 100 mm |
Laser Distance Sensor Features at a Glance Miniature design 2 mutually independent switching outputs IO-Link interface Large working range Optical Data Working Range 0 … 1,500 mm Setting Range 50 … 1,500 mm Switching Hysteresis < 30 mm Light Source Laser (infrared) Wavelength 940 nm Service Life (T = +25 °C) 100,000 h Laser Class (EN 60825-1) 1 Max. Ambient Light 10,000 Lux Light Spot Diameter see Table 1
Add to cart
Laser Distance Sensor Features at a Glance Industrial Ethernet Measured value independent of material, color and brightness Web server and graphic display for simple operation CMOS line array Optical Data Working Range 60 … 660 mm Measuring Range 600 mm Reproducibility maximum 70 … 1,000 µm Linearity Deviation 100 … 1,000 µm Light Source Laser (red) Wavelength 655 nm Service Life (T = +25 °C) 100,000 h Laser … Continue reading OCP662P0150P →
Add to cart
Laser Distance Sensor Features at a Glance Smallest recognizable distance difference: 200 µm Spot diameter: 0,8 mm Optical Data Range 100 mm Setting Range 60 … 100 mm Switching Hysteresis < 200 µm Light Source Laser (red) Wavelength 660 nm Service Life (T = +25 °C) 100,000 h Laser Class (EN 60825-1) 2 Max. Ambient Light 10,000 Lux Light Spot Diameter 0.8 mm Focus Distance 110 mm
Add to cart
Laser Distance Sensor Features at a Glance 2 mutually independent switching outputs Graphical display for easy operation Switching output A1 as analog output switchable (0…10 V/4…20 mA) Temperature drift eliminable Optical Data Working Range 0.1 … 10.1 m Measuring Range 10 m Resolution 1 … 12 mm Linearity 0.5 % Linearity Deviation 50 mm Switching Hysteresis 3 … 20 mm Light Source Laser (red) Wavelength 660 nm Service … Continue reading Y1TA100QXT3 →
Add to cart
